FR (Fire Retardant) and FRLS (Fire Retardant Low Smoke) Wires are specially designed to provide enhanced safety during fire incidents. These wires are manufactured using high-quality electrolytic copper conductors and specially formulated PVC compounds that resist flame propagation while minimizing smoke emission and toxic gases.
| Parameter | Specification |
|---|---|
| Conductor Material | Electrolytic Grade Copper |
| Insulation | FR / FRLS PVC Compound |
| Voltage Grade | Up to 1100 V |
| Standard | IS 694 |
| Conductor Type | Multistrand Flexible Copper |
| Temperature Rating | Up to 70°C |
| Insulation Resistance | High |
| Flame Retardancy | Excellen |
| Wire Size | Current Capacity (Approx.) |
|---|---|
| 0.75 sq mm | 8 A |
| 1.0 sq mm | 11 A |
| 1.5 sq mm | 14 A |
| 2.5 sq mm | 24 A |
| 4 sq mm | 32 A |
| 6 sq mm | 40 A |
| 10 sq mm | 55 A |
| 16 sq mm | 75 A |
| Feature | FR Wire | FRLS Wire |
|---|---|---|
| Flame Retardant | Yes | Yes |
| Smoke Emission | Normal | Very Low |
| Toxic Gas Emission | Moderate | Low |
| Fire Safety | Good | Superior |
| Recommended For | Residential Use | High-Rise Buildings, Hospitals, Schools, Commercial Spaces |
✔ Excellent Fire Resistance
✔ Restricts Flame Propagation
✔ Low Smoke Generation (FRLS)
✔ Reduced Toxic Gas Emission
✔ High Conductivity Copper Conductors
✔ Superior Flexibility & Easy Installation
✔ Long Service Life
✔ Enhanced Electrical Safety
